Introduction:
WORKING PRINCIPLEThe purified and heated air is introduced from the bottom by the draft fan and passed through the screen plate. The fluidization is formed through stirring and negative pressure in the working room. The moisture will be rapidly evapor…
This dryer is widely used for the following materials:
1) Damp granules and powder materials in pharmaceutical, foodstuff, feed, chemi cal, and agrochemical industries.
2) Granules made by extruder, oscillating granulator, and high speed mixing granulator.
3) Special large granule and small blocks that having adhesive property.
4) The material that changes volume during drying process; such as konjak.
Item | Model | ||||||
Feeding Capacity (kg) | 60 | 100 | 120 | 150 | 200 | 300 | 500 |
Fan Power (kw) | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 45 |
Stirring Power (kw) | 0.55 | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | 2.2 |
Stirring Speed (rpm) | 8~11 | ||||||
Steam Consumption (kg/h) | 141 | 170 | 170 | 240 | 282 | 366 | 451 |
Working Time (min) | 15-30(It depends on the nature of materials) | ||||||
Dryer Heigh (mm) | 2700 | 2900 | 2900 | 2900 | 2900 | 3300 | 3500 |
